Fixed Athermalized IR Lens 19mm f/1.0
- group name
- Fixed Athermalized LWIR Lens (1-FOV)
- Min Order
- 1 piece
- brand name
- Quanhom Optronics
- model
- GLA1910A
- Nearest port for product export
- Shanghai, Ningbo, Tianjin, Khorgos
- Delivery clauses under the trade mode
- FOB, CFR, CIF, EXW, CIP, FCA, CPT, DDP, DDU, Express Delivery, DAF, DES
- Acceptable payment methods
- T/T, D/P D/A, PayPal, Westem Union
- update time
- Thu, 21 Nov 2024 17:53:58 GMT
Paramtents
LWIR Lens 19mm f/1.0
Applications Security and Surveillance
Mechanical Interface Thread
Packging & Delivery
-
Min Order1 piece
Briefing
Fixed LWIR Lens，can be applied to Thermal Imaging Body Temperature Screening
Detailed
- Specifications
- Download file
- FAQ
- Video
- Applications
Specifications
|
HFOV
|
160x120
|
320x240
|
336x256 | 384x288 | 640x480 | 640x512 | 1024x768 |
1280x1024
|
|
17μm
|
8.2°
|
16.3°
|
17.1° | 19.5° | 32.0° | 32.0° | / |
/
|
|
12μm
|
5.8°
|
11.5°
|
12.1° | 13.8° | 22.9° | 22.9° | / |
/
|
Optical |
|||
|
Focal Length[mm]
|
19
|
||
|
F/#
|
1.0
|
||
Average Transmission | >80% | ||
Format | Φ14 | ||
Mechanical |
|||
|
Fixed Athermalized
|
||
|
|
||
|
Weight
|
|
||
Environmental |
|||
|
Operating Temperature
|
-40℃ to +80℃
|
||
|
External Coating
|
AR
|
||
Sealing | IP67 | ||
Download document
|
file name
|
type |
download
|
||
PDF |
|
|||
FAQ
What is the difference between GLA1910 and GLA1910A?
1.The GLA1910 is clearly different from the GLA1910A in appearance.
2.GLA1910's first lens is coated with DLC/AR film, GLA1910A's first lens is coated with AR film.
3.The GLA1910 mounting thread is M25*0.5 11mm and the GLA1910A mounting thread is M25*0.5 11mm,GLA1910A mounting thread is M34*0.5-6g 4.52mm.
APPLICATIONS
Airborne
Enhanced Vision
Hand-held Thermal Imaging Devices
Homeland Security
Maritime & Naval
Security & Surveillance
